Fireproof Tasteless Acoustic Wood Ceiling , Odorless Sound Absorbing Acoustic Panel

100 square meters
Fireproof Tasteless Acoustic Wood Ceiling , Odorless Sound Absorbing Acoustic Panel
Features Gallery Product Description Request A Quote
Product Name: Fire Resistant Sound Absorb Material
Size: W600*D21*H2400mm
Length: Available In 2400mm To 3000mm Lengths
Color: Color Chart Or Customized
Fireproof Grade: Class A
ECO Grade: Class E1
Finish: Fire Rated Material With Melamine/HPL/veneer
OEM&ODM: Available
High Light:

Fireproof Acoustic Wood Ceiling


Tasteless Acoustic Wood Ceiling


Odorless Sound Absorbing Acoustic Panel

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: CYATCO
Certification: SGS, CE, FSC
Model Number: AWP-141029
Payment & Shipping Terms
Packaging Details: carton / As customer required
Delivery Time: 10-20 work days
Payment Terms: L/C, T/T
Supply Ability: 50000 Square Meters Per Month
Product Description

Acoustic Wooden Slat Wall Panels Fire Resistant Sound Absorb Material



Product Parameters


Product Name Fire Resistant Sound Absorb Material
Pattern MDF 27mm, Edge to edge 13mm / customized
Standard Size 2400*600*21mm / customized
MDF Thickness 12mm/15mm/18mm
Polyester Thickness 9mm/12mm
Finish Melamine / Veneer / Painting
Material Basic: Engineered Veneer+MDF +Felt made of recycled plastic Bottleshe
Surface: Fireproof finished / Wood Finished / Melamine Finished
Bottom PET polyester panel
Test Eco protection, Sound absorption, Fire-retardant
Function Sound absorption / Interior decoration
Noise Reduction Coefficient

0.85~0.94,SGS Test for polyester panel




Product Features:

1. With excellent sound absorbing performance. The NRC can be 0.85 to 0.94.
2. Easy to cut by knife and easy to install by glue or nail.
3. Good physical stability, will not inflate or shrink due to the change of temperature.
4. Soft and natural texture. It will not get broken under huge impact of high elasticity.
5. Easy dust removal and easy maintenance by vacuum cleaner or feather dust.




Ensure clear language and reduce echoes in gymnasiums, badminton halls, tennis courts, etc.

Reduce echo to increase speech and music clarity in theaters, cinemas, concert halls, churches, etc.

Inprove indoor environmental quality and comfort in museums, hospitals, rail station, airport, etc.

Improve speech intelligibility in classroom, function room.

Acoustic treatment to meet the design of offices, hotels, banquet halls, restaurants, etc.


Product Installation


Panels can be mounted with very few tools - the panel is mounted on 5 horizontal bars with black screws. You will find E0 hot glue,spray glue or gun nail to install on the wall. Here,the underlying walls are painted white on top and black on bottom. Extra attention was paid to detail and the edges of the doors and Windows were decorated with elegant oak lines. Since the panels are mounted on the joists/wooden beams, they can be removed again. This makes them suitable for rental homes that would otherwise not be able to be painted, wallpapered or similar variations.
1. Install 45mm (thickness) battens directly to your wall/ceiling with a distance of 600mm.
2. Install the acoustic panels directly on the battens with screws (min. 3.5mm × 35mm). You can easily fit the screws between the lamellas into the underlying acoustic felt. Every panel is installed with 15 screws.
3. Cutting the panels is easily done with a fine jagged saw. The underlying acoustic felt is easily cut with a good knife.
4. For an expanded acoustic solution, you can place 45mm insulation between the studs.


Fireproof Tasteless Acoustic Wood Ceiling , Odorless Sound Absorbing Acoustic Panel 0Fireproof Tasteless Acoustic Wood Ceiling , Odorless Sound Absorbing Acoustic Panel 1
